Suprema G-200

Product lines > Multi purpose chairs > Gynecological chairs

4 Motors

2 years warranty

Custom colors

Description

Suprema G200: 4 powerful motors of high quality (up to 8000N) for the independent movement of up/down, backrest, seat and legrest.

The solid construction in metal painted with epoxy powders and electro-zincate, armrest as anti-panic handle.

Removable and adjustable along the side guide (as alternative are available also standard upholstered armrests) as well as 4 stainless steel lateral rails (on seat and backrest) grants the maximum reliability of this chair.

The upholstered parts of the chair are composed of high-density and non-deformable foam pelted with bi-elastic, tear resistant, antimicrobial skai, very easy to clean.

More than 40 nuances available.

Details and optionals

Different inclinations and positions to be selected

Different inclinations and positions to be selected by the operator, with the possibility to reach Trendelenburg position.

Padded Footrests, optional

Padded Footrests shaped and adjustable in height and inclination.

Anatomical Leg rest, optional

Anatomical Leg rest pelted in the same color of the chair's upholstery, adjustable in height and inclination.

Multifunction foot control

Multifunction foot control (WIRELESS version optional) for the control of each chair’s movements, provided with 4 memories: 3 positions chosen by the operator and 1 to recall the resting position of the chair (“zero” position).

Metal basin, optional

Metal basin, with capacity 2 lt. Available also with drainage tube. Optional accessory.

Paper roll support, optional

Central cushion for filling the empty space between seat and single-legrest. Highly advisable in bed position, for increasing the patient comfort. Optional accessory.

Paper roll support, optional

Paper roll support, placed on the backrest. Optional accessory

Technical details

NAME	VALUE
Power supply tension	100-240 VAC 50/60 Hz
Fuses	F1=F2=1,6 AT
Max absorbed power	200VA
Class according to IEC 60601-1	IB
Sectionable power feading cable	L=3mt
Lifting motor	Spinta 8000N
Backrest motor	Spinta 6000N
Trendelenburg motor	Spinta 6000N
Legrest motor	Spinta 2500N
Lifting capacity	200 Kg
Chair weight	200 Kg
Lifting excursion, Trendelenburg inclination	350 mm, 20° +/- 2°

Download data sheet
