Otocompact Professional EVO
Optional Application:
- Application of second suction system
- Application of single-use suction jar (1 or 2 lt. capacity)
- Automatic discharge system Automatic rinsing system for suction tube
- Connection to the water main
- Application of kit for medicaments, available up to 6 medicament bottles
- Warming system for 2 endoscope supports
- Pole support for microscope with articulated arm for monitor
- Video-Endoscopy system
- Microscope
- Video Nystagmoscope
- Rhinomanometer
Description
ENT Top Range workstation with a state-of-the-art integrated technology and elegant and unique design.
Solid case in steel painted with epoxy powders in color silver grey or white RAL 9003. Transparent gloss layer for easy cleaning and better protection against external agents (optional). Such treatment grants a long durability in time and high resistance of the colors to the light.
The case is also mobile on 6 antistatic castors with brakes that help the operator in the floor cleaning and sanification as well as in the easy positioning anywhere in the outpatient room.
Working top in tempered glass. linear surface for an easier disinfection against proliferation of bacteria.
Standard Applications:
- Color and adjustable touch screen 7''
- Wireless control of the motorized movement of the combined chair, if present
- Working top in temperated and colored crystal ( at choice among 20 nuances)
- Motorized drawers in metal, epoxy painted or in tempered and colored glass ( at choice among 20 nuances)
- Powered suction system (50 lt/min or 70 lt/min) complete with suction jar (1 lt. capacity)
- Hydrophobic filter
- Kit of stainless steel suction canulas
- Ear funnel
- Insufflation system with digital manometer
- Ear washing syringe with fixed temperature 37°
- Mirror warmer
- Integrated 3-channel LED light source - 5.500°K 200 L with f.o. cables
- Integrated LED light source with handpiece for direct connection to endoscopes
- Nr. 8 integrated endoscope supports in Plexiglass
- Nr. 2 supports for headlamp
Details
Standard Applications
Technical details
| NAME | VALUE |
|---|---|
| Power supply tension | 220/240 V(110/115 VAC) |
| Frequency | 50/60 Hz |
| Absorbed power (MAX maximum configuration) | 1550 VA |
| Weight | 180 Kg |
| Maximum number of instruments | 4 |
| Insufflator air flow | 26 l/m (variation up to 250 Kpa) |
| Washing stringe capacity | 350 cc/min (at 2 Bar) |
| Nominal suction (oil motor) | -86 Kpa (-650 mm Hg 50 L/min) |
| Power supply fuses | F1, F2 = 6,3 A T |
| Fuse external Plug | F3 = 4 A T |
